Up to 54 nodes when DVC-EM is used in network paging Modules include addressable pull stations, normally open contact devices, two-wire smoke detectors, notification, or relay wireless modules are available for use with the FWSG.Detectors can be any mix of photo, thermal, or multi-sensor wireless detectors are available for use with the SWIFT Wireless Gateway (FWSG).Up to 159 detectors and 159 modules per SLC 318 devices per loop/3,180 per FACP or network node.Wireless fire protection using SWIFT® Smart Wireless Integrated Fire Technology.Easy expansion of N16x power capacity (one expandable to three PMB-AUX power supplies).One expandable to three on N16e (three cards in the cabinet).Easy expansion of isolated intelligent Signaling Line Circuit (SLC) capacity.NACs support up to 3 patterns of output to allow dynamic signaling based on system events: Temp-3 (Fire), Temp-4 (CO), two-stage evacuation, selective silence.
NACs support selectable System Sensor, Wheelock, and Gentex strobe synchronization.Four Class A/B power outputs that can be configured as Class A/B Notification Appliance Circuits (NACs), power circuit, door holder circuit, or Universal Zone Coding circuit (UZC licensable option).Two auxiliary Class A/B outputs configurable for resettable or non-resettable operation.6.0 A power supply with customizable outputs.Expandable to a total of 3 power supplies.6 amps total power for System, Loop and NAC’s.10” HD touchscreen display or no display.Expandable up to ten loops 3180 total devices.Scalable addressable life safety system.A host of other options are available, including single or multichannel integrated voice firefighter’s telephone and many additional options. Optional enclosure sizes are available to support additional peripheral equipment. The N16x can support one to 10 SLM-318 modules, for a capacity of up to 3,180 intelligent addressable devices on 10 SLC loops. Panels can be configured for stand-alone or network systems. NOTIFIER INSPIRE N16x Fire Alarm Control Panel NOTIFIER INSPIRE N16x Fire Alarm Control Panel Multiple Off-Premise Communication Options.Available remote programming for connected panels.Standard and Advanced Detection Capabilities.Marine and Seismic to be added in the future.Synchronized using System Sensor Strobes, Wheelock and Gentex.318 devices per loop (159 detector/159 modules).One part number comes with enclosure, power supply, loop, CPU and display.Single scalable addressable life safety system.Simply add additional peripheral equipment to suit the application. Panels can be configured with just a few devices for small building applications or networked with many devices to protect a large campus or a high-rise office block. The panel ships with power supply PMB-AUX to support four NACs and two auxiliary outputs. Up two additional Signaling Line Modules (SLM-318) can be added, expanding capacity to 954 intelligent addressable devices on three Signaling Line Circuit (SLC) loops. Offered in a standard preconfigured enclosure, the N16e comes with one Signaling Line Module to support 318 intelligent addressable devices. NOTIFIER INSPIRE N16e Fire Alarm Control Panel NOTIFIER INSPIRE N16e Fire Alarm Control Panel
